Emory Endoscopic Plastic Surgery Retractor

Emory Endoscopic Retractor with 10mm Scope Guide

The Emory endoscopic retractor combines tissue retraction and scope guidance in one instrument. Its integrated guide holds a 10mm endoscope, and a compression screw locks the scope in place. In addition, a built-in channel evacuates cautery smoke, so the surgeon keeps a clear view of the pocket throughout the case.

Why surgeons use it

In endoscopic surgery, the assistant must hold both the tissue and the camera steady. This retractor does both jobs, so one hand is free. As a result, the view stays stable while you dissect, and the image does not drift when the assistant tires.

• Integrated guide for 10mm endoscopes
• Compression screw locks the scope in position
• Built-in smoke evacuation channel
• Three blade sizes for different pocket depths
• Ergonomic handle for a secure grip

Applications of the Emory endoscopic retractor

Surgeons use this instrument mainly in endoscopic breast augmentation, especially for transaxillary and subpectoral pocket dissection. It also suits endoscopic abdominoplasty, brow lift and other endoscope-assisted plastic surgery. For background on implant procedures, see the American Society of Plastic Surgeons guide to breast augmentation.

Choosing a blade size

• 120 x 22mm: narrow blade for smaller pockets and tighter access.
• 120 x 25mm: the standard size for most breast pockets.
• 150 x 25mm: longer blade for deep pockets and larger patients.

Specifications

• Blade sizes: 120 x 22mm, 120 x 25mm, 150 x 25mm
• Scope guide: 10mm endoscopes
• Material: medical-grade German stainless steel
• Finish: satin, to reduce glare under the light source
• Reusable and autoclavable

Care and sterilization

Flush the smoke channel and the scope guide right after use, because blood dries quickly in narrow lumens. Then clean with a soft brush, rinse, dry and autoclave. Our instrument care guide explains each step. For a full endoscopic tray, read our breast augmentation instruments checklist.

Browse our breast dissectors and fiber optic retractors, or request a quote for wholesale and OEM orders. We ship worldwide, and every instrument carries a 3-month warranty.
